WL455C is a minimalist and elegantly compact bedside lamps, crafted from metal and featuring precision lens optics paired with SMD7070 light sources. The design is defined by clean lines and refined dimensions, offering both functional illumination and enhanced spatial aesthetics. Equipped with an integrated switch, the lamps are well-suited for contemporary living environments and support TRIAC dimming.
Application: Mainly used for modern home bedside lighting, such as: home, hotel, hospital etc.
| Code | WL455C-3W | ||
|---|---|---|---|
| Dimension(mm) | 156*37*68 | ||
| Watt(W) | 3W | ||
| Rated Input Voltage | AC220-240V | ||
| Input Voltage | AC198-264V | ||
| LED Module Input | 36V | ||
| Light Source | SMD | ||
| SDCM | SDCM<5 | ||
| CCT(K) | 1-CCT: 2700K/3000K/4000K | ||
| CCT Selection DIP Switch | NO | ||
| Luminous Flux (lm) ±5% | 1-CCT | DIM | 300-350 |
| CRI90 | |||
| CRI | 90 | ||
| Beam Angle(°) | 30°/40° | ||
| UGR | <22 | ||
| LED Driver | Driver built-in | ||
| Dimming Option | Triac | ||
| Sensor | NO | ||
| Emergency Kits | NO | ||
| Electrical Class | Class I | ||
| Ingress Protection(IP Rating) | IP20 | ||
| Impact Resistance(IK Rating) | - | ||
| Product Finishing | White RAL9016 / Black RAL9005 | ||
| Optics Material | PMMA | ||
| Housing Material | Die-Casting Aluminium | ||
| Lifetime(hr) | 50,000h | ||
| Glow wire test(°C) | 650°C | ||
| Operating Temp.(°C) | -20°C~40°C | ||
| Storage Temp.(°C) | -20°C~65°C | ||
| Installation | Wall mount | ||
