ST2 LED Strip Light RGB
ST2 LED Strip Light RGB 2
ST2 LED Strip Light RGB 3
ST2 LED Strip Light RGB 4
ST2 LED Strip Light RGB
ST2 LED Strip Light RGB 2
ST2 LED Strip Light RGB 3
ST2 LED Strip Light RGB 4

ST2 LED Strip Light RGB

  • With soft and uniform lighting effect, dot free.
  • IP20/IP54/IP65 protection level available.
  • Cutable for flexible application.

Applications: It is suitable for supermarket, specialty store, show window, exhibition hall; focus lighting, decorative and background lighting, where attention is focused on subjects to emphasize special visual points.

Specification Files
Specifications

ST201 Series, 320LED/M,10W/M, R/G/B, 50mm CUT

Product Code Led Qty IP grade PCB width Power(W) Color Lumen/M Lumen/W CRI Voltage Voltage range Reverse Voltage Length/Reel Min cut Beam angle Working Temperature Storage Temperature
ST201-24P0TV-COBR-320S-10W-M 320 IP20 8mm 10W/M Red 175 lm 18 lm / DC24V DC 23V-25V DC25V 10M/5M 50mm 180° -40 ~60°C -25 ~40°C
ST201-24P0TV-COBG-320S-10W-M Green 950 lm 95 lm
ST201-24P0TV-COBB-320S-10W-M Blue 145 lm 15 lm
ST201-24P4TV-COBR-320S-10W-M 320 IP54 8mm 10W/M Red 175 lm 18 lm / DC24V DC 23V-25V DC25V 10M/5M 50mm 180° -40 ~60°C -25 ~40°C
ST201-24P4TV-COBG-320S-10W-M Green 950 lm 95 lm
ST201-24P4TV-COBB-320S-10W-M Blue 145 lm 15 lm
ST201-24P5TV-COBR-320S-10W-M 320 IP65 8mm 10W/M Red 165 lm 17 lm / DC24V DC 23V-25V DC25V 5M 50mm 140° -40 ~60°C -25 ~40°C
ST201-24P5TV-COBG-320S-10W-M Green 930 lm 93 lm
ST201-24P5TV-COBB-320S-10W-M Blue 140 lm 14 lm



ST206 Series, 420LED/M,12W/M, RGB, 50mm CUT

Product Code Led Qty IP grade PCB width Power(W) Color Lumen/M Lumen/W CRI Voltage Voltage range Reverse Voltage Length/Reel Min cut Beam angle Working Temperature Storage Temperature
ST206-24P0TV-COBRGB-420S-12W/M 420 IP20 10mm 12W/M RGB R: 84lm G: 348lm B: 36lm R: 7lm G: 29lm B: 3lm / DC24V DC 23V-25V DC25V 10M/5M 50mm 180° -40 ~60°C -25 ~40°C
ST206-24P4TV-COBRGB-420S-12W/M 420 IP54 10mm 12W/M RGB R: 84lm G: 348lm B: 36lm R: 7lm G: 29lm B: 3lm / DC24V DC 23V-25V DC25V 10M/5M 50mm 180° -40 ~60°C -25 ~40°C
ST206-24P5TV-COBRGB-420S-12W/M 420 IP65 10mm 12W/M RGB R: 81lm G: 337lm B: 34lm R: 7lm G: 28lm B: 3lm / DC24V DC 23V-25V DC25V 5M 50mm 140° -40 ~60°C -25 ~40°C



ST203 Series, 576LED/M,12W/M, RGB, 31.25mm CUT

Product Code Led Qty IP grade PCB width Power(W) Color Lumen/M Lumen/W CRI Voltage Voltage range Reverse Voltage Length/Reel Min cut Beam angle Working Temperature Storage Temperature
ST203-24P0TV-COBRGB-576D-12W-M 576 IP20 10mm 12W/M RGB R: 60lm G: 768lm B: 120lm R: 5lm G: 64lm B: 10lm / DC24V DC 23V-25V DC25V 5M 31.25mm 180° -40 ~60°C -25 ~40°C
ST203-24P4TV-COBRGB-576D-12W-M 576 IP54 10mm 12W/M RGB R: 60lm G: 768lm B: 120lm R: 5lm G: 64lm B: 10lm / DC24V DC 23V-25V DC25V 5M 31.25mm 180° -40 ~60°C -25 ~40°C
ST203-24P5TV-COBRGB-576D-12W-M 576 IP65 10mm 12W/M RGB R: 58lm G: 744lm B: 116lm R: 5lm G: 64lm B: 10lm / DC24V DC 23V-25V DC25V 5M 31.25mm 140° -40 ~60°C -25 ~40°C



ST207 Series, 840LED/M,12W/M, RGB, 25mm CUT

Product Code Led Qty IP grade PCB width Power(W) Color Lumen/M Lumen/W CRI Voltage Voltage range Reverse Voltage Length/Reel Min cut Beam angle Working Temperature Storage Temperature
ST207-24P0TV-COBRGB-840S-12W-M 840 IP20 10mm 12W/M RGB R: 87lm G: 365lm B: 38lm R: 8lm G: 31lm B: 4lm / DC24V DC 23V-25V DC25V 5M 25mm 180° -40 ~60°C -25 ~40°C
ST207-24P4TV-COBRGB-840S-12W-M 840 IP54 10mm 12W/M RGB R: 87lm G: 365lm B: 38lm R: 8lm G: 31lm B: 4lm / DC24V DC 23V-25V DC25V 5M 25mm 180° -40 ~60°C -25 ~40°C
ST207-24P5TV-COBRGB-840S-12W-M 840 IP65 10mm 12W/M RGB R: 56lm G: 354lm B: 37lm R: 5lm G: 30lm B: 4lm / DC24V DC 23V-25V DC25V 5M 25mm 140° -40 ~60°C -25 ~40°C



ST203 Series, 576LED/M, 6W/M, IRGB, 31.25mm CUT

Product Code Led Qty IP grade PCB width Power(W) Color Lumen/M Lumen/W CRI Voltage Voltage range Reverse Voltage Length/Reel Min cut Beam angle Working Temperature Storage Temperatu
ST203-24P0TV-COBIRGB-576D-6W-M 576 IP20 8mm 6W/M IRGB R: 168lm G: 546lm B: 126lm R: 28lm G: 91lm B: 21lm / DC24V DC 23V-25V DC25V 5M 31.25mm 180° -40 ~60°C -25 ~40°C
ST203-24P4TV-COBIRGB-576D-6W-M 576 IP54 8mm 6W/M IRGB R: 168lm G: 354lm B: 126lm R: 28lm G: 91lm B: 21lm / DC24V DC 23V-25V DC25V 5M 31.25mm 180° -40 ~60°C -25 ~40°C
ST203-24P5TV-COBIRGB-576D-6W-M 576 IP65 8mm 6W/M IRGB R: 162lm G: 327lm B: 122lm R: 27lm G: 55lm B: 21m / DC24V DC 23V-25V DC25V 5M 31.25mm 140° -40 ~60°C -25 ~40°C



ST208 Series, 360LED/M, 4W/M, IRGB, 100mm CUT

Product Code Led Qty IP grade PCB width Power(W) Color Lumen/M Lumen/W CRI Voltage Voltage range Reverse Voltage Length/Reel Min cut Beam angle Working Temperature Storage Temperatu
ST208-24P0TV-COBIRGB-360D-4W-M 360 IP20 10mm 4W/M IRGB R: 160lm G: 520lm B: 120lm R: 40lm G: 130lm B: 30lm / DC24V DC 23V-25V DC25V 10M/5M 100mm 180° -40 ~60°C -25 ~40°C
ST208-24P4TV-COBIRGB-360D-4W-M 360 IP54 10mm 4W/M IRGB R: 160lm G: 520lm B: 120lm R: 40lm G: 130lm B: 30lm / DC24V DC 23V-25V DC25V 10M/5M 100mm 180° -40 ~60°C -25 ~40°C
ST208-24P5TV-COBIRGB-360D-4W-M 360 IP65 10mm 4W/M IRGB R: 155lm G: 504lm B: 116lm R: 39lm G: 126lm B: 29lm / DC24V DC 23V-25V DC25V 5M 100mm 140° -40 ~60°C -25 ~40°C
