Applications: It is suitable for supermarket, specialty store, show window, exhibition hall; focus lighting, decorative and background lighting, where attention is focused on subjects to emphasize special visual points.
| Product Code | Led Qty | IP grade | PCB width | Power(W) | Color Temperature | Lumen/M | Lumen/W | CRI | Voltage | Voltage range | Reverse Voltage | Length/Reel | Min cut | Beam angle | Working Temperature | Storage Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ST209-24P0TV-COB-528D-10W-M | 528 | IP20 | 8mm | 10W/M | 2700K | 660lm | 66lm | CRI90 | DC24V | DC 23V-25V | DC25V | 5M | Free cut | 180° | -40 ~60°C | -25 ~40°C |
| 3000K | 660lm | 66lm | ||||||||||||||
| 4000K | 670lm | 67lm | ||||||||||||||
| 6500K | 670lm | 67lm | ||||||||||||||
| ST209-24P4TV-COB-528D-10W-M | 528 | IP54 | 8mm | 10W/M | 2700K | 660lm | 66lm | CRI90 | DC24V | DC 23V-25V | DC25V | 5M | Free cut | 180° | -40 ~60°C | -25 ~40°C |
| 3000K | 660lm | 66lm | ||||||||||||||
| 4000K | 670lm | 67lm | ||||||||||||||
| 6500K | 670lm | 67lm |
| Product Code | Led Qty | IP grade | PCB width | Power(W) | Color Temperature | Lumen/M | Lumen/W | CRI | Voltage | Voltage range | Reverse Voltage | Length/Reel | Min cut | Beam angle | Working Temperature | Storage Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ST210-24P0TV-COB-1000D-10W-M | 1000 | IP20 | 8mm | 10W/M | 2700K | 900lm | 90lm | CRI90 | DC24V | DC 23V-25V | DC25V | 5M | Free cut | 180° | -40 ~60°C | -25 ~40°C |
| 3000K | 900lm | 90lm | ||||||||||||||
| 4000K | 950lm | 95lm | ||||||||||||||
| 6500K | 950lm | 95lm | ||||||||||||||
| ST210-24P4TV-COB-1000D-10W-M | 1000 | IP54 | 8mm | 10W/M | 2700K | 900lm | 90lm | CRI90 | DC24V | DC 23V-25V | DC25V | 5M | Free cut | 180° | -40 ~60°C | -25 ~40°C |
| 3000K | 900lm | 90lm | ||||||||||||||
| 4000K | 950lm | 95lm | ||||||||||||||
| 6500K | 950lm | 95lm |
