Applications: It is suitable for supermarket, specialty store, show window, exhibition hall; focus lighting, decorative and background lighting, where attention is focused on subjects to emphasize special visual points.
| Product Code | Led Qty | IP grade | PCB width | Power(W) | Color Temperature | Lumen/M | Lumen/W | CRI | Voltage | Voltage range | Reverse Voltage | Length/Reel | Min cut | Beam angle | Working Temperature | Storage Temperature | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ST201-24P0TV-COB-320S-10W-M | 320 | IP20 | 8mm | 10W/M | 2000K | 830 lm | 83 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 10M/5M | 50mm | 180° | -40 ~60°C | -25 ~40°C | |
| 2700K | 850 lm | 85 lm | |||||||||||||||
| 3000K | 850 lm | 85 lm | |||||||||||||||
| 3500K | 890 lm | 89 lm | |||||||||||||||
| 4000K | 950 lm | 95 lm | |||||||||||||||
| 6500K | 950 lm | 95 lm | |||||||||||||||
| ST201-24P4TV-COB-320S-10W-M | 320 | IP54 | 8mm | 10W/M | 2000K | 830 lm | 83 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 10M/5M | 50mm | 180° | -40 ~60°C | -25 ~40°C | |
| 2700K | 850 lm | 85 lm | |||||||||||||||
| 3000K | 850 lm | 85 lm | |||||||||||||||
| 3500K | 890 lm | 89 lm | |||||||||||||||
| 4000K | 950 lm | 95 lm | |||||||||||||||
| 6500K | 950 lm | 95 lm | |||||||||||||||
| ST201-24P5TV-COB-320S-10W-M | 320 | IP65 | 8mm | 10W/M | 2000K | 805 lm | 81 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 5M | 50mm | 140° | -40 ~60°C | -25 ~40°C | |
| 2700K | 825 lm | 83 lm | |||||||||||||||
| 3000K | 825 lm | 83 lm | |||||||||||||||
| 3500K | 863 lm | 87 lm | |||||||||||||||
| 4000K | 921 lm | 93 lm | |||||||||||||||
| 6500K | 921 lm | 93 lm | |||||||||||||||
| Product Code | Led Qty | IP grade | PCB width | Power(W) | Color Temperature | Lumen/M | Lumen/W | CRI | Voltage | Voltage range | Reverse Voltage | Length/Reel | Min cut | Beam angle | Working Temperature | Storage Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ST205-24P0TV-COB-400S-8W-M | 400 | IP20 | 8mm | 8W/M | 2000K | 700 lm | 88 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 10M/5M | 10mm | 180° | -40 ~60°C | -25 ~40°C |
| 2700K | 720 lm | 90 lm | ||||||||||||||
| 3000K | 720 lm | 90 lm | ||||||||||||||
| 3500K | 740 lm | 93 lm | ||||||||||||||
| 4000K | 760 lm | 95 lm | ||||||||||||||
| 6500K | 760 lm | 95 lm | ||||||||||||||
| ST205-24P4TV-COB-400S-8W-M | 400 | IP54 | 8mm | 8W/M | 2000K | 700 lm | 88 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 10M/5M | 10mm | 180° | -40 ~60°C | -25 ~40°C |
| 2700K | 720 lm | 90 lm | ||||||||||||||
| 3000K | 720 lm | 90 lm | ||||||||||||||
| 3500K | 740 lm | 93 lm | ||||||||||||||
| 4000K | 760 lm | 95 lm | ||||||||||||||
| 6500K | 760 lm | 95 lm | ||||||||||||||
| ST205-24P5TV-COB-400S-8W-M | 400 | IP65 | 8mm | 8W/M | 2000K | 679 lm | 85 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 5M | 10mm | 140° | -40 ~60°C | -25 ~40°C |
| 2700K | 698 lm | 88 lm | ||||||||||||||
| 3000K | 698 lm | 88 lm | ||||||||||||||
| 3500K | 717 lm | 90 lm | ||||||||||||||
| 4000K | 737 lm | 93 lm | ||||||||||||||
| 6500K | 737 lm | 93 lm |
| Product Code | Led Qty | IP grade | PCB width | Power(W) | Color Temperature | Lumen/M | Lumen/W | CRI | Voltage | Voltage range | Reverse Voltage | Length/Reel | Min cut | Beam angle | Working Temperature | Storage Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ST202-24P0TV-COB-640D-15W-M | 640 | IP20 | 10mm | 15W/M | 2000K | 1400 lm | 94 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 10M/5M | 50mm | 180° | -40 ~60°C | -25 ~40°C |
| 2700K | 1425 lm | 95 lm | ||||||||||||||
| 3000K | 1425 lm | 95 lm | ||||||||||||||
| 3500K | 1450 lm | 97 lm | ||||||||||||||
| 4000K | 1500 lm | 100 lm | ||||||||||||||
| 6500K | 1500 lm | 100 lm | ||||||||||||||
| ST202-24P4TV-COB-640D-15W-M | 640 | IP54 | 10mm | 15W/M | 2000K | 1400 lm | 94 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 10M/5M | 50mm | 180° | -40 ~60°C | -25 ~40°C |
| 2700K | 1425 lm | 95 lm | ||||||||||||||
| 3000K | 1425 lm | 95 lm | ||||||||||||||
| 3500K | 1450 lm | 97 lm | ||||||||||||||
| 4000K | 1500 lm | 100 lm | ||||||||||||||
| 6500K | 1500 lm | 100 lm | ||||||||||||||
| ST202-24P5TV-COB-640D-15W-M | 640 | IP65 | 10mm | 15W/M | 2000K | 1358 lm | 91 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 5M | 50mm | 140° | -40 ~60°C | -25 ~40°C |
| 2700K | 1382 lm | 93 lm | ||||||||||||||
| 3000K | 1382 lm | 93 lm | ||||||||||||||
| 3500K | 1406 lm | 94 lm | ||||||||||||||
| 4000K | 1455 lm | 97 lm | ||||||||||||||
| 6500K | 1455 lm | 97 lm |
| Product Code | Led Qty | IP grade | PCB width | Power(W) | Color Temperature | Lumen/M | Lumen/W | CRI | Voltage | Voltage range | Reverse Voltage | Length/Reel | Min cut | Beam angle | Working Temperature | Storage Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ST203-24P0TV-COBTW-576S-16W-M | 576 | IP20 | 8mm | 16W/M | 2700K-6000K | 2700K 680lm 6000K 775lm | 2700K 85lm 6000K 97lm | CRI90 | DC24V | DC 23V-25V | DC25V | 5M | 27.78mm | 180° | -40 ~60°C | -25 ~40°C |
| ST203-24P4TV-COBTW-576S-16W-M | 576 | IP54 | 8mm | 16W/M | 2700K-6000K | 2700K 680lm 6000K 775lm | 2700K 85lm 6000K 97lm | CRI90 | DC24V | DC 23V-25V | DC25V | 5M | 27.78mm | 180° | -40 ~60°C | -25 ~40°C |
| ST203-24P5TV-COBTW-576S-16W-M | 576 | IP65 | 8mm | 16W/M | 2700K-6000K | 2700K 660lm 6000K 751lm | 2700K 83lm 6000K 94lm | CRI90 | DC24V | DC 23V-25V | DC25V | 5M | 27.78mm | 140° | -40 ~60°C | -25 ~40°C |
