This track light is an anti-glare design. High lumen COB chip and PMMA lens offer a uniform lighting output. AL6063 aluminum lamp body provides excellent heat dissipation. Special lens design reaches anti-glare effect and creates a comfortable visual experience. Multiple beam angle lens optional, modular lens design make a convenient maintenance. Easy installation, recreational for various application.
LED kitchen track light features:
• Anti-glare design
• CRI80/90/97 available
• Modular lens design: 30°/45°for 10W, 36°/60°for 20W and above
• SDCM<6
• Flicker free internal driver
| Code No. | TL228-10W | TL228-15W | TL228-20W | TL228-25W | TL228-30W | TL228-40W |
|---|---|---|---|---|---|---|
| Dimension(mm) | Ø65*249 | Ø85*269 | Ø100*302 | |||
| Watt(W) | 10W | 15W | 20W | 25W | 30W | 40W |
| Rated Input Voltage(V) | AC230V | |||||
| Input Voltage(V) | AC200—240V | |||||
| Light Source | COB | |||||
| SDCM | <6 | |||||
| CCT(K) | 1-CCT: 2700K/3000K/4000K/5000KK|| 3-CCT: 3000K + 3500K + 5000K | |||||
| CCT Selection DIP Switch | Yes | |||||
| Non-DIM 1-CCTLuminous Flux (lm) ±5% | 780-1100 | 1200-1500 | 1200-1500 | 2150-2700 | 2650-3050 | 3550-4200 |
| Non-DIM 3-CCTLuminous Flux (lm) ±5% | 500-850 | 750-1200 | 1600-2000 | 1850-2350 | 2100-2650 | - |
| CRI | 80/90/97(1-CCT) /90(3-CCT) | |||||
| Beam Angle (°) | 24°/30°/45° | 24°/36°/60° | ||||
| LED Driver | Built-in | |||||
| Electrical Class | Class Ⅰ | |||||
| Ingress Protection (IP Rating) | IP20 | |||||
| Product Finishing(Base) | White RAL 9016/Black RAL9005 | |||||
| Materials of Optics | PMMA | |||||
| Materials of Housing | PC/Aluminum | |||||
| Lifetime (hr) | 5,0000h | |||||
| Glow wire test (℃ ) | 650℃ | |||||
| Operating Temp. (℃ ) | -20℃ ~40℃ | |||||
| Storage Temp. (℃ ) | -20℃ ~65℃ | |||||
| Installation | Track | |||||
TL228 (G2.0)
| Code | TL228-10W | TL228-15W | TL228-15W-D | TL228-20W | TL228-25W | TL228-30W | TL228-40W | ||
|---|---|---|---|---|---|---|---|---|---|
| Dimension(mm) | Ø65*215 | Ø85*236 | Ø100*269 | ||||||
| Watt(W) | 10W | 15W | 15W | 20W | 25W | 30W | 40W | ||
| Rated Input Voltage | AC230V | ||||||||
| Input Voltage | AC200-240V | ||||||||
| Light Source | COB | ||||||||
| SDCM | <6 | ||||||||
| CCT(K) | 1-CCT: 2700K/3000K/4000K/5000K|| 3-CCT: 3000K + 4000K + 5000K | ||||||||
| CCT Selection DIP Switch | Yes | NO | |||||||
| Luminous Flux (lm) ±5% CRI80 | 1-CCT | Non-DIM | 900-1100 | 1350-1650 | - | 1800-2250 | 2150-2700 | 2650-3050 | 3550-4200 |
| DIM | 850-1050 | - | 1350-1650 | 1750-2150 | 1950-2450 | 2450-2800 | - | ||
| 3-CCT | Non-DIM | 750-950 | 1050-1400 | - | 1750-2100 | 2150-2600 | 2300-2850 | - | |
| DIM | 700-890 | - | 1050-1400 | 1700-2050 | 1950-2350 | 2100-2650 | - | ||
| CRI | 1CCT: 80(90) / 3CCT: 90 | 1CCT:80 (90) | |||||||
| Beam Angle(°) | 24°/36°/60° | ||||||||
| LED Driver | Built-in | ||||||||
| Dimming Option | Triac | NO | Triac | Triac | Triac | Triac | NO | ||
| Electrical Class | Class I | ||||||||
| Ingress Protection(IP Rating) | IP20 | ||||||||
| Impact Resistance(IK Rating) | IK03 | ||||||||
| Product Finishing | White RAL 9016/Black RAL9005 | ||||||||
| Optics Material | PMMA | ||||||||
| Housing Material | Aluminum | ||||||||
| Lifetime(hr) | 50,000h | ||||||||
| Glow wire test(°C) | 650°C | ||||||||
| Operating Temp.(°C) | -20°C~40°C | ||||||||
| Storage Temp.(°C) | -20°C~65°C | ||||||||
| Installation | Track | ||||||||
