Features:
Applications: It is suitable for supermarket, specialty store, show window, exhibition hall; focus lighting, decorative and background lighting, where attention is focused on subjects to emphasize special visual points.
| Product Code | Led Qty | IP grade | PCB width | Power(W) | Color Temperature | Lumen/M | Lumen/W | CRI | Voltage | Voltage range | Reverse Voltage | Length/Reel | Min cut | Beam angle | Working Temperature | Storage Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ST209-24P0TV-COB-528D-10W-M | 528 | IP20 | 8mm | 10W/M | 2000K | 600lm | 60lm | CRI90 | DC24V | DC 23V-25V | DC25V | 10m/5m | Free cut | 180° | -25~45°C | -40~65°C |
| 2700K | 660lm | 66lm | ||||||||||||||
| 3000K | 660lm | 66lm | ||||||||||||||
| 3500K | 680lm | 68lm | ||||||||||||||
| 4000K | 700lm | 70lm | ||||||||||||||
| 6500K | 700lm | 70lm | ||||||||||||||
| ST209-24P4TV-COB-528D-10W-M | 528 | IP54 | 8mm | 10W/M | 2000K | 600lm | 60lm | CRI90 | DC24V | DC 23V-25V | DC25V | 10m/5m | Free cut | 180° | -25~45°C | -40~65°C |
| 2700K | 660lm | 66lm | ||||||||||||||
| 3000K | 660lm | 66lm | ||||||||||||||
| 3500K | 680lm | 68lm | ||||||||||||||
| 4000K | 700lm | 70lm | ||||||||||||||
| 6500K | 700lm | 70lm | ||||||||||||||
| ST209-24P5TV-COB-528D-10W-M | 528 | IP65 | 8mm | 10W/M | 2000K | 560lm | 56lm | CRI90 | DC24V | DC 23V-25V | DC25V | 10m/5m | Free cut | 140° | -25~45°C | -40~65°C |
| 2700K | 620lm | 62lm | ||||||||||||||
| 3000K | 620lm | 62lm | ||||||||||||||
| 3500K | 620lm | 62lm | ||||||||||||||
| 4000K | 650lm | 65lm | ||||||||||||||
| 6500K | 650lm | 65lm | ||||||||||||||
| ST209-24P7TV-COB-528D-10W-M | 528 | IP67 | 8mm | 10W/M | 2000K | 540lm | 54lm | CRI90 | DC24V | DC 23V-25V | DC25V | 10m/5m | Free cut | 140° | -25~45°C | -40~65°C |
| 2700K | 600lm | 60lm | ||||||||||||||
| 3000K | 620lm | 62lm | ||||||||||||||
| 3500K | 620lm | 62lm | ||||||||||||||
| 4000K | 650lm | 65lm | ||||||||||||||
| 6500K | 650lm | 65lm |
