Features:
Applications: It is suitable for supermarket, specialty store, show window, exhibition hall; focus lighting, decorative and background lighting, where attention is focused on subjects to emphasize special visual points.
| Product Code | Led Qty | IP grade | PCB width | Power(W) | Color | Lumen/M | Lumen/W | Voltage | Voltage range | Reverse Voltage | Length/Reel | Min cut | Beam angle | Working Temperature | Storage Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ST207-24P0TV-COBRGB-840D-12W-M | 840 | IP20 | 10mm | 12W/M | RGB | R: 87lm G: 365lm B: 38lm | R: 8lm G: 31lm B: 4lm | DC24V | DC 23V-25V | DC25V | 5M | 25mm | 180° | -25 ~45°C | -40 ~65°C |
| ST207-24P4TV-COBRGB-840D-12W-M | 840 | IP54 | 10mm | 12W/M | RGB | R: 87lm G: 365lm B: 38lm | R: 8lm G: 31lm B: 4lm | DC24V | DC 23V-25V | DC25V | 5M | 25mm | 180° | -25 ~45°C | -40 ~65°C |
| ST207-24P5TV-COBRGB-840D-12W-M | 840 | IP65 | 10mm | 12W/M | RGB | R: 56lm G: 354lm B: 37lm | R: 5lm G: 30lm B: 4lm | DC24V | DC 23V-25V | DC25V | 5M | 25mm | 140° | -25 ~45°C | -40 ~65°C |
