Features:
Applications: It is suitable for supermarket, specialty store, show window, exhibition hall; focus lighting, decorative and background lighting, where attention is focused on subjects to emphasize special visual points.
| Product Code | Led Qty | IP grade | PCB width | Power(W) | Color | Lumen/M | Lumen/W | CRI | Voltage | Voltage range | Reverse Voltage | Length/Reel | Min cut | Beam angle | Working Temperature | Storage Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ST206-24P0TV-COBRGB-420S-12W/M | 420 | IP20 | 10mm | 12W/M | RGB | R: 84lm G: 348lm B: 36lm | R: 7lm G: 29lm B: 3lm | / | DC24V | DC 23V-25V | DC25V | 10M/5M | 50mm | 180° | -25 ~45°C | -40 ~65°C |
| ST206-24P4TV-COBRGB-420S-12W/M | 420 | IP54 | 10mm | 12W/M | RGB | R: 84lm G: 348lm B: 36lm | R: 7lm G: 29lm B: 3lm | / | DC24V | DC 23V-25V | DC25V | 10M/5M | 50mm | 180° | -25 ~45°C | -40 ~65°C |
| ST206-24P5TV-COBRGB-420S-12W/M | 420 | IP65 | 10mm | 12W/M | RGB | R: 81lm G: 337lm B: 34lm | R: 7lm G: 28lm B: 3lm | / | DC24V | DC 23V-25V | DC25V | 5M | 50mm | 140° | -25 ~45°C | -40 ~65°C |
