Features:
Applications: It is suitable for supermarket, specialty store, show window, exhibition hall; focus lighting, decorative and background lighting, where attention is focused on subjects to emphasize special visual points.
| Product Code | Led Qty | IP grade | PCB width | Power(W) | Color | Lumen/M | Lumen/W | Voltage | Voltage range | Reverse Voltage | Length/Reel | Min cut | Beam angle | Working Temperature | Storage Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ST203-24P0TV-COBRGB-576D-12W-M | 576 | IP20 | 10mm | 12W/M | RGB | R: 60lm G: 768lm B: 120lm | R: 5lm G: 64lm B: 10lm | DC24V | DC 23V-25V | DC25V | 5M | 31.25mm | 180° | -25 ~45°C | -40 ~65°C |
| ST203-24P4TV-COBRGB-576D-12W-M | 576 | IP54 | 10mm | 12W/M | RGB | R: 60lm G: 768lm B: 120lm | R: 5lm G: 64lm B: 10lm | DC24V | DC 23V-25V | DC25V | 5M | 31.25mm | 180° | -25 ~45°C | -40 ~65°C |
| ST203-24P5TV-COBRGB-576D-12W-M | 576 | IP65 | 10mm | 12W/M | RGB | R: 58lm G: 744lm B: 116lm | R: 5lm G: 64lm B: 10lm | DC24V | DC 23V-25V | DC25V | 5M | 31.25mm | 140° | -25 ~45°C | -40 ~65°C |
| Product Code | Led Qty | IP grade | PCB width | Power(W) | Color | Lumen/M | Lumen/W | Voltage | Voltage range | Reverse Voltage | Length/Reel | Min cut | Beam angle | Working Temperature | Storage Temperatu |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ST203-24P0TV-COBIRGB-576D-6W-M | 576 | IP20 | 8mm | 6W/M | IRGB | R: 168lm G: 546lm B: 126lm | R: 28lm G: 91lm B: 21lm | DC24V | DC 23V-25V | DC25V | 5M | 31.25mm | 180° | -25 ~45°C | -40 ~65°C |
| ST203-24P4TV-COBIRGB-576D-6W-M | 576 | IP54 | 8mm | 6W/M | IRGB | R: 168lm G: 354lm B: 126lm | R: 28lm G: 91lm B: 21lm | DC24V | DC 23V-25V | DC25V | 5M | 31.25mm | 180° | -25 ~45°C | -40 ~65°C |
| ST203-24P5TV-COBIRGB-576D-6W-M | 576 | IP65 | 8mm | 6W/M | IRGB | R: 162lm G: 327lm B: 122lm | R: 27lm G: 55lm B: 21m | DC24V | DC 23V-25V | DC25V | 5M | 31.25mm | 140° | -25 ~45°C | -40 ~65°C |
