Features:
Applications: It is suitable for supermarket, specialty store, show window, exhibition hall; focus lighting, decorative and background lighting, where attention is focused on subjects to emphasize special visual points.
| Product Code | Led Qty | IP grade | PCB width | Power(W) | Color Temperature | Lumen/M | Lumen/W | CRI | Voltage | Voltage range | Reverse Voltage | Length/Reel | Min cut | Beam angle | Working Temperature | Storage Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ST202-24P0TV-COB-640D-15W-M | 640 | IP20 | 10mm | 15W/M | 2000K | 1400 lm | 94 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 10M/5M | 50mm | 180° | -25~45°C | -40~65°C |
| 2700K | 1425 lm | 95 lm | ||||||||||||||
| 3000K | 1425 lm | 95 lm | ||||||||||||||
| 3500K | 1450 lm | 97 lm | ||||||||||||||
| 4000K | 1500 lm | 100 lm | ||||||||||||||
| 6500K | 1500 lm | 100 lm | ||||||||||||||
| ST202-24P4TV-COB-640D-15W-M | 640 | IP54 | 10mm | 15W/M | 2000K | 1400 lm | 94 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 10M/5M | 50mm | 180° | -25~45°C | -40~65°C |
| 2700K | 1425 lm | 95 lm | ||||||||||||||
| 3000K | 1425 lm | 95 lm | ||||||||||||||
| 3500K | 1450 lm | 97 lm | ||||||||||||||
| 4000K | 1500 lm | 100 lm | ||||||||||||||
| 6500K | 1500 lm | 100 lm | ||||||||||||||
| ST202-24P5TV-COB-640D-15W-M | 640 | IP65 | 10mm | 15W/M | 2000K | 1358 lm | 91 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 5M | 50mm | 140° | -25~45°C | -40~65°C |
| 2700K | 1382 lm | 93 lm | ||||||||||||||
| 3000K | 1382 lm | 93 lm | ||||||||||||||
| 3500K | 1406 lm | 94 lm | ||||||||||||||
| 4000K | 1455 lm | 97 lm | ||||||||||||||
| 6500K | 1455 lm | 97 lm |
