Features:
Applications: It is suitable for supermarket, specialty store, show window, exhibition hall; focus lighting, decorative and background lighting, where attention is focused on subjects to emphasize special visual points.
| Product Code | Led Qty | IP grade | PCB width | Power(W) | Color Temperature | Lumen/M | Lumen/W | CRI | Voltage | Voltage range | Reverse Voltage | Length/Reel | Min cut | Beam angle | Working Temperature | Storage Temperature | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ST201-24P0TV-COB-320S-10W-M | 320 | IP20 | 8mm | 10W/M | 2000K | 830 lm | 83 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 10M/5M | 50mm | 180° | -25~45°C | -40~65°C | |
| 2700K | 850 lm | 85 lm | |||||||||||||||
| 3000K | 850 lm | 85 lm | |||||||||||||||
| 3500K | 890 lm | 89 lm | |||||||||||||||
| 4000K | 950 lm | 95 lm | |||||||||||||||
| 6500K | 950 lm | 95 lm | |||||||||||||||
| ST201-24P4TV-COB-320S-10W-M | 320 | IP54 | 8mm | 10W/M | 2000K | 830 lm | 83 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 10M/5M | 50mm | 180° | -25~45°C | -40~65°C | |
| 2700K | 850 lm | 85 lm | |||||||||||||||
| 3000K | 850 lm | 85 lm | |||||||||||||||
| 3500K | 890 lm | 89 lm | |||||||||||||||
| 4000K | 950 lm | 95 lm | |||||||||||||||
| 6500K | 950 lm | 95 lm | |||||||||||||||
| ST201-24P5TV-COB-320S-10W-M | 320 | IP65 | 8mm | 10W/M | 2000K | 805 lm | 81 lm | CRI90 | DC24V | DC 23V-25V | DC25V | 5M | 50mm | 140° | -25~45°C | -40~65°C | |
| 2700K | 825 lm | 83 lm | |||||||||||||||
| 3000K | 825 lm | 83 lm | |||||||||||||||
| 3500K | 863 lm | 87 lm | |||||||||||||||
| 4000K | 921 lm | 93 lm | |||||||||||||||
| 6500K | 921 lm | 93 lm | |||||||||||||||
