The led spot module is high cost-effective and high performance. With compact appearance design and diameter Ø50mm, it is able to match with standard bracket. It adopts aluminium material for lamp body which makes good heat dissipation. When Ta<=25°C, it can be abutted against normally flammable materials, including building insulation. CCT interchangeable DIP switch on back of the lamp body helps save SKU. IP54 in front and the efficiency is up to 130lm/W @4000K.
Application Areas: Widely used for all kinds of interiors, including office, supermarket, shop, school, hotel, stairwell, lobby, reception desk, corridor and so on.
| Code | SP28-6W-DC3 | ||
|---|---|---|---|
| Dimension(mm) | Ø50*53 | ||
| Watt(W) | 6W | ||
| Rated Input Voltage | AC220-240V | ||
| Input Voltage | AC198-264V | ||
| Light Source | SMD | ||
| SDCM | <6 | ||
| CCT(K) | 3-CCT: 3000K + 4000K + 5700K | ||
| CCT Selection | By DIP Switch | ||
| Luminous Flux (lm) ±5% CRI80 | 3-CCT | DIM | 650-720 |
| CRI | CRI80 | ||
| Beam Angle(°) | 60° | ||
| LED Driver | Built-in, Flicker Free | ||
| Dimming Option | Triac | ||
| Sensor | NO | ||
| Emergency Kits | NO | ||
| Electrical Class | Class II | ||
| Ingress Protection(IP Rating) | IP54(Below Ceiling), IP40(Inside Ceiling) | ||
| Impact Resistance(IK Rating) | IK03 | ||
| Product Finishing | White RAL9016 | ||
| Optics Material | PC | ||
| Housing Material | Plastic coated Aluminium | ||
| Lifetime(hr) | 40,000h | ||
| Glow wire test(°C) | 750°C | ||
| Operating Temp.(°C) | -20°C~45°C (25°C IC-4) | ||
| Storage Temp.(°C) | -20°C~65°C | ||
| Installation | Recessed | ||
