New LED troffer light adopts secondary optical designed and special treatment diffuser to achieve more uniform and softer light, providing more comfortable visual experience. Luminous efficiency 105lm/W. Powder spraying surface treatment is employed in the lamp fixture which makes the lamp corrosion resistant. Designed for grid ceiling commercial applications.
LED troffer panel light features
| Model No. | GL6060-33W-N | GL30120-33W-N | ||||
| Watt(W) | 33W | 33W | ||||
| Dimension(mm) | 595×595×54 | 1195×295×54 | ||||
| Input Voltage(V) | 220 – 240 V | 220 – 240 V | ||||
| LED | SMD | |||||
| SDCM | ≦6 | |||||
| CCT(K) | 1-CCT: 3000K/4000K/5000K/5700K || 3-CCT: 3000K + 4000K + 5700K | |||||
| Luminous Flux (lm) ±5% |
Non-DIM | 1-CCT | 3100-3800 | 3100-3800 | ||
| DIM | 3000-3700 | 3000-3700 | ||||
| Non-DIM | 3-CCT | 3100-3850 | 3100-3850 | |||
| DIM | 3000-3750 | 3000-3750 | ||||
| CRI | CRI≧80 | |||||
| Beam Angle (°) | 120° | |||||
| LED Driver | built-out | |||||
| CCT Selection Switch | YES | |||||
| Protection Class | Class Ⅱ | |||||
| IP Rating | IP20 | |||||
| Finishing color | White RAL 9016 | |||||
| Material | PC/Fe | |||||
| Lifetime (hr) | 50000 | |||||
| Glow wire test (°C) | 750°C | |||||
| Operating Temp.(°C) | -20℃～45℃ | |||||
| Storage Temp.(°C) | -20℃～65℃ | |||||
| Installation | Recessed | |||||
