This is an adjustable LED pendant light featuring a high-efficiency SMD light source and an integrated isolation power supply. It has wire rope clip that allows manual height adjustment. The lamp shape with wider at the top and narrower at the bottom, creates a symmetrical shape with the ceiling plate. The top cover has a push button which enables CCT interchangeable 1800K+3000K, 3000K+4000K, enhancing its modern appeal for various lifestyles and settings.
Applications: It's widely used in dining room, kitchen, balcony, bar table, gifts shop, cafe etc.
| Code | PD229B-100-15W-C2 | PD229B-100-15W-C2 | ||
|---|---|---|---|---|
| Dimension(mm) | Ø100*1500 | Ø100*1500 | ||
| Watt(W) | 15W | |||
| Watt(W) | Direct light: 9W, Indirect light: 6W | |||
| Rated Input Voltage | AC220-240V | |||
| Input Voltage | AC198-264V | |||
| Light Source | SMD | |||
| SDCM | SDCM<6 | |||
| CCT(K) | 2-CCT: 1800K+3000K | 2-CCT: 3000K+4000K | ||
| CCT Selection DIP Switch | YES | |||
| Luminous Flux (lm) ±5% CRI90 | 2-CCT | Non-DIM | 770-1230 | 1130-1240 |
| CRI | CRI 90 | |||
| Beam Angle(°) | Direct light: 80°, Indirect light: 60° | |||
| LED Driver | Built-in, Flicker Free | |||
| Sensor | No | |||
| Emergency Kits | No | |||
| Electrical Class | Class I | |||
| Ingress Protection(IP Rating) | IP20 | |||
| Impact Resistance(IK Rating) | IK03 | |||
| Product Finishing | Black RAL9005 | |||
| Optics Material | PC | |||
| Housing Material | Die-Casting Aluminium | |||
| Lifetime(hr) | 50,000h | |||
| Glow wire test(°C) | 750°C | |||
| Operating Temp.(°C) | -20°C~45°C | |||
| Storage Temp.(°C) | -20°C~65°C | |||
| Installation | Pendant | |||
