The unique wavy appearance, the clean and tidy surface of the lamp body without any screws, adds an artistic touch and a distinctive visual effect to the entire series. The visually appealing design enhances the aesthetics of the space, while the high-quality lighting performance ensures the optimal lighting effect. The aluminum 6063 lamp body ensures good heat management and a longer lifespan. The surface is sprayed with 280# sand-textured powder, giving it a smooth and textured appearance, and also adopts a high CRI90 LED chip to better restore the color of objects.
Applications: It's widely used in specialty stores, shop windows, offices, hotels, exhibition halls, studios, cafés, corridors, museums, libraries, high-end residences, and supermarkets.
| Code | PD147-30250-8W-D | PD147-45150-8W-D | PD147-65150-12W-D | ||
|---|---|---|---|---|---|
| Dimension(mm) | Ø30*H1295 | Ø45*H1195 | Ø65*H1195 | ||
| Watt(W) | 8W | 8W | 12W | ||
| Rated Input Voltage | AC220-240V | ||||
| Input Voltage | AC198-264V | ||||
| Light Source | COB | ||||
| SDCM | SDCM<5 | ||||
| CCT(K) | 3000K/4000K | ||||
| Luminous Flux (lm) ±5% CRI90 | 1-CCT | DIM | 500-540 | 570-650 | 1050-1130 |
| CRI | CRI90 | ||||
| Beam Angle(°) | 24°/36° | ||||
| UGR | ≤19 | ||||
| LED Driver | Built-in | ||||
| Dimming Option | Triac | ||||
| Electrical Class | Class I | ||||
| Ingress Protection(IP Rating) | IP20 | ||||
| Impact Resistance(IK Rating) | IK02 | ||||
| Product Finishing | White RAL9016, Black RAL9005 | ||||
| Optics Material | PC | ||||
| Housing Material | Aluminium 6063 | ||||
| Lifetime(hr) | 50,000h | ||||
| Glow wire test(°C) | 750°C | ||||
| Operating Temp.(°C) | -20°C~40°C | ||||
| Storage Temp.(°C) | -20°C~65°C | ||||
| Installation | Pendant | ||||
