This is an IP65 waterproof wall light for outdoor applications. The housing is made of high-strength aerospace aluminum and a UV-resistant PC cover, strong protection level with waterproof, dust-proof, and corrosion resistance. The surface is available in matte black RAL9005 or slate gray RAL7015, blending harmoniously with the environment. It adopts high efficiency LED chip and PMMA lens for uniform illumination and can effectively reduce glare.
Applications: It's widely used in indoor and outdoor scene lighting area, such as yard, green landscape, business street, garden, park etc.
| Code | ART-WL185-10W | ||
|---|---|---|---|
| Dimension(mm) | Ø100*77 | ||
| Watt(W) | 10W | ||
| Rated Input Voltage | AC220~240V | ||
| Input Voltage | AC198~264V | ||
| Light Source | SMD2835 | ||
| SDCM | <6 | ||
| CCT(K) | 1-CCT: 2700K/3000K/4000K | ||
| Luminous Flux (lm) ±5% CRI80 | 1-CCT | Non-DIM | 775-855lm |
| CRI | CRI80 | ||
| Beam Angle(°) | 120° | ||
| LED Driver | Built-in, Flicker Free | ||
| Electrical Class | Class I | ||
| Ingress Protection(IP Rating) | IP65 | ||
| Impact Resistance(IK Rating) | IK08 | ||
| Product Finishing | Black RAL9005/Grey RAL7015 | ||
| Optics Material | PC | ||
| Housing Material | Die-Casting Aluminium | ||
| Lifetime(hr) | 50,000h | ||
| Glow wire test(°C) | 750°C | ||
| Operating Temp.(°C) | -20°C~45°C | ||
| Storage Temp.(°C) | -20°C~65°C | ||
| Installation | Wall mount | ||
