This RGB LED down light adopts Tuya Bluetooth wireless control system, which brings the regulation of lighting, group controlling, timing, scene setting, music melodies and many other functions. It adopts high lumen SMD and RGB light source to reach both RGB and brightness+CCT adjustable function. The smart luminous effect gives people the enjoyment of beauty. The plastic-coated aluminum housing and integrated driver design, which provide good thermal management and great popularity by the excellent dimming effect. There are flat version and recessed version are optional, and the flat version can replace different color trims to meet the needs of different occasions and different architectural styles.
Applications: It is designed for general lighting applications such as home, office, shop, hotel, restaurant etc.
| Code | DL457A-3-7W-B3-I01 | DL457B-3-7W-B3-I01 |
|---|---|---|
| Dimension(mm) | Ø115*H59 | |
| Cutout(mm) | Ø90-95 | |
| Watt(W) | 7W | |
| Rated Input Voltage | AC200-240V | |
| Input Voltage | AC198-264V | |
| Light Source | SMD | |
| SDCM | SDCM<6 | |
| CCT(K) | 2700K-6500K+RGB | |
| CCT Selection | Control via the Tuya App | |
| Luminous Flux (lm) ±5% CRI80 | 830-900 | 780-840 |
| CRI | 80 | |
| Beam Angle(°) | 100° | |
| LED Driver | Built-in, Flicker Free | |
| Dimming Option | Control via the Tuya App | |
| Electrical Class | Class II | |
| Ingress Protection(IP Rating) | IP54(Below Ceiling), IP20(Inside Ceiling) | |
| Impact Resistance(IK Rating) | IK03 | |
| Product Finishing | White RAL9016 | |
| Optics Material | PC | |
| Housing Material | Plastic coated Aluminium | |
| Lifetime(hr) | 50,000h | |
| Glow wire test(°C) | 650°C | |
| Operating Temp(°C) | -20°C-45°C | |
| Storage Temp(°C) | -20°C-65°C | |
| Installation | Recessed | |
