| Dimension(mm) | Ø115*67 | Ø145*79 | Ø170*94 | Ø190*99 | Ø235*113 |
| Cutout (mm) | Ø90-95 | Ø120-130 | Ø140-150 | Ø160-170 | Ø200-210 |
| Watt(W) | 8W | 10W | 13W | 15W | 18W | 15W | 20W | 25W | 18W | 25W | 30W |
| Rated Input Voltage | AC220-240V |
| Input Voltage | AC198-264V |
| LED Module Input | DC30-40V |
| Light Source | SMD |
| SDCM | <6 |
| CCT(K) | 1-CCT: 3000K/4000K/5000K/5700K ||2-CCT:3000K+ 4000K |
| CCT Selection DIP Switch | YES |
| Non-DIM 1-CCT Luminous Flux (lm) ±5% CRI80 | 950-1000 | 1200-1400 | 1550-1700 | 1850-1900 | 2100-2300 | 1900-2000 | 2550-2700 | 3100-3300 | 2300-2500 | 3300-3500 | 3900-4150 |
| DIM 1-CCT Luminous Flux (lm) ±5% CRI80 | 950-1000 | 1200-1400 | 1500-1650 | 1850-1900 | 2000-2200 | 1900-2000 | 2500-2650 | 3100-3300 | 2250-2450 | 3300-3500 | 3650-3880 |
| Non-DIM 2-CCT Luminous Flux (lm) ±5% CRI80 | 900-950 | 1200-1350 | 1550-1700 | 1750-1900 | 2050-2150 | 1800-1900 | 2450-2500 | 2950-3000 | 2300-2500 | 3300-3550 | 3850-4250 |
| DIM 2-CCT Luminous Flux (lm) ±5% CRI80 | 900-950 | 1200-1350 | 1500-1650 | 1750-1900 | 2000-2100 | 1800-1900 | 2400-2450 | 2950-3000 | 2250-2450 | 3300-3550 | 3600-4000 |
| CRI | 80 |
| Beam Angle (°) | 60° |
| UGR | <19 | <19 | <19 | <19 | <19 | <19 | <19 | <22 | <19 | <19 | <19 |
| LED Driver | Driver built-out |
| Dimming Option | Triac |
| Electrical Class | Class II |
| Ingress Protection(IP Rating) | IP54(Below Ceiling), IP20(Inside Ceiling) |
| Impact Resistance(IK Rating) | IK03 |
| Product Finishing | White RAL9016, Black RAL9005 |
| Optics Material | PC |
| Housing Material | Aluminium |
| Lifetime (hr) | 50,000h |
| Glow wire test (°C) | 750°C |
| Operating Temp.(°C) | -20°C~45°C |
| Storage Temp.(°C) | -20°C~65°C |
| Installation | Recessed / Surface mount |
