Up-shine DL38 surface mounted ceiling light adopts COB led chip. Aluminium profile provides excellent thermal dissipation. Isolated driver solution both in dimmable and non-dimmable version achieves stable working performance.
Application: Suitable for commercial and residential applications like office, supermarket, shop, school, hotel, restaurant, workshop, warehouse, home etc.
| Code No. | DL38B-10W | DL38B-15W | DL38B-20W | DL38B-25W | DL38B-25W | DL38B-32W |
|---|---|---|---|---|---|---|
| Dimension(mm) | Ø120*110 | Ø160*120 | ||||
| Watt(W) | 10W | 15W | 20W | 25 | 25W | 32W |
| Rated Input Voltage(V) | AC230V | |||||
| Input Voltage(V) | AC220V—240V | |||||
| Light Source | COB | |||||
| CCT(K) | 1-CCT: 2700K/3000K/4000K/5000K | |||||
| Non-DIM 1-CCT Luminous Flux (lm) ±5% | 1100-1500 | 1600-1950 | - | 2600-2950 | 3000-3300 | 3150-3680 |
| DIM 1-CCT Luminous Flux (lm) ±5% | 1000-1300 | 1500-1850 | 2100-2400 | 2500-2800 | 2950-3250 | 3100-3550 |
| CRI | ≥80 | |||||
| Beam Angle (°) | 24° / 36° / 60° | |||||
| LED Driver | Built-in | |||||
| Dimming Option | Triac / Dali | |||||
| Electrical Class | Class I | |||||
| Ingress Protection (IP Rating) | IP54 | |||||
| Product Finishing(Base) | White RAL9016 / Black RAL9005 | |||||
| Materials of Optics | PC | |||||
| Materials of Housing | Aluminum Die-casting | |||||
| Lifetime (hr) | 50,000h | |||||
| Glow wire test (°) | 850°C | |||||
| Operating Temp. (°) | -20°~40°C | |||||
| Storage Temp. (°) | -20°~65°C | |||||
| Installation | Surface mount | |||||
