Code |
CL156-2.5-8W |
CL156-3-10W |
CL156-3-13W |
CL156-4-18W |
CL156-4-25W |
CL156-6-18W |
CL156-6-25W |
CL156-6-35W |
||
|---|---|---|---|---|---|---|---|---|---|---|
|
Dimension(mm) |
Ø80*32 |
Ø110*47 |
Ø140*65 |
Ø180*81 |
||||||
|
Cutout(mm) |
Ø68-75 |
Ø90-95 |
Ø120-130 |
Ø160-170 |
||||||
|
Watt(W) |
8W |
10W |
13W |
18W |
25W |
18W |
25W |
35W |
||
|
Rated Input Voltage |
AC220-240V |
|||||||||
|
Input Voltage |
AC198-264V |
|||||||||
|
LED Module Input |
DC33-38V |
|||||||||
|
Light Source |
COB |
|||||||||
|
SDCM |
<5 |
|||||||||
|
CCT(K) |
3-CCT: 3000K+4000K+5000K |
|||||||||
|
CCT Selection DIP Switch |
YES |
|||||||||
|
Luminous Flux (lm) ±5% CRI80 |
3-CCT |
Non-DIM |
- |
1030-1100 |
1230-1310 |
1900-1960 |
2540-2685 |
1925-1976 |
2590-2720 |
3400-3730 |
|
|
|
DIM |
- |
1010-1050 |
1200-1260 |
1865-1925 |
2410-2565 |
1890-1940 |
2465-2600 |
3300-3600 |
|
Luminous Flux (lm) ±5% CRI90 |
3-CCT |
Non-DIM |
570-640 |
- |
- |
- |
- |
- |
- |
- |
|
|
|
DIM |
550-610 |
- |
- |
- |
- |
- |
- |
- |
|
CRI |
90 |
80 |
||||||||
|
Beam Angle (°) |
36° |
|||||||||
|
LED Driver |
Driver built-out |
|||||||||
|
Dimming Option |
Triac |
|||||||||
|
Electrical Class |
Class II |
|||||||||
|
Ingress Protection(IP Rating) |
IP20 |
|||||||||
|
Product Finishing |
White RAL9016 / Black RAL9005 |
|||||||||
|
Optics Material |
PC |
|||||||||
|
Housing Material |
Die-Casting Aluminium |
|||||||||
|
Lifetime(hr) |
50,000h |
|||||||||
|
Glow wire test (°C) |
750°C |
|||||||||
|
Operating Temp(°C) |
-20°C~45°C |
|||||||||
|
Storage Temp(°C) |
-20°C~65°C |
|||||||||
|
Installation |
Recessed |
|||||||||
