This is a gyro design square shape downlight. Adopt high lumen COB light source, ADC12 aluminum housing provides a great heat dissipation. For structure design, it is tilted 23° in all directions (360°), perfectly meet the demands of different lighting angle, cutout 83mm, with loop in/out driver which supports quick install and maintenance. Besides, it’s available for Dim-to-Warm version (2000K~3000K),
Application Areas: It is designed for general lighting applications in office, supermarket, shop, school, hotel, etc.
| Code No. | CL130B-2.5-8W | CL130B-2.5-15W | CL130B-2.5- 8W-DW | CL130B-2.5- 15W-DW | ||||
|---|---|---|---|---|---|---|---|---|
| Dimension(mm) | 97*97*45 | 177*97*45 | 97*97*45 | 177*97*45 | ||||
| Cutout (mm) | Ø83 | |||||||
| Watt(W) | 8W | 15W | 8W | 15W | ||||
| Rated Input Voltage(V) | AC230V | |||||||
| Input Voltage(V) | AC220-240V | |||||||
| LED Module Input | DC33-38V | |||||||
| Light Source | COB | |||||||
| SDCM | <6 | |||||||
| CCT(K) | 1-CCT: 2700K/3000K/4000K/5000 | WW: 2000-3000K | ||||||
| CCT Selection DIP Switch | No | YES | ||||||
| Non-DIM 1-CCT Luminous Flux (lm) ±5% | 730-890 | 650-785 | 500-690 | 1380-1550 | 1230-1380 | 1050-1280 | - | - |
| DIM 1-CCT Luminous Flux (lm) ±5% | 700-850 | 620-750 | 450-620 | 1350-1510 | 1200-1340 | 1000-1200 | - | - |
| DIM CCT change Luminous Flux (lm) ±5% | - | 350-420 | 750-840 | |||||
| CRI | 80 | 90 | 95 | 80 | 90 | 95 | 90-97 | |
| Beam Angle (°) | 15°/24°36°/60° | |||||||
| LED Driver | Built-out | |||||||
| Dimming Option | Triac | |||||||
| Electrical Class | ClassII | |||||||
| Ingress Protection (IP Rating) | IP54（only for the LED cover) | |||||||
| Product Finishing(Base) | White RAL9016/Black RAL9005/Sliver RAL9006 | |||||||
| Materials of Optics | PC+Aluminium | |||||||
| Materials of Housing | Aluminium Die-casting | |||||||
| Lifetime (hr) | 50,000h | |||||||
| Glow wire test (℃ ) | 750℃ | |||||||
| Operating Temp. (℃ ) | -20℃ ~45℃ | |||||||
| Storage Temp. (℃ ) | -20℃ ~65℃ | |||||||
| Installation | Recessed | |||||||
