Application Areas: It is designed for general lighting applications in office, supermarket, shop, school, hotel, etc.
| CODE | ART-AL99C-16-20W | ART-AL99C-24-40W | ART-AL99C-32-75W | ART-AL99C-40-100W | ||
|---|---|---|---|---|---|---|
|
Dimension(mm) |
Ø400*86 |
Ø600*86 |
Ø800*86 |
Ø1000*86 |
||
|
Cutout(mm) |
Ø220~250 |
Ø385~415 |
||||
|
Watt(W) |
20W |
40W |
75W |
100W |
||
|
Input Voltage |
AC198-264V |
|||||
|
LED Module Input |
- |
|||||
|
Light Source |
SMD |
|||||
|
CCT(K) |
1-CCT: 3000K/4000K || 2-CCT: 3000K + 4000K |
|||||
|
CCT Selection DIP Switch |
YES |
|||||
|
Luminous Flux (lm) ±5% (White or Wood grain finish)CRI80 |
1-CCT |
Non-DIM |
1420-1780 |
3800-4580 |
7700-8580 |
9480-10250 |
|
DALI |
1350-1680 |
3690-4280 |
7350-8210 |
9400-9750 |
||
|
2-CCT |
Non-DIM |
1400-1750 |
3750-4500 |
7650-8500 |
9400-10200 |
|
|
DALI |
1300-1680 |
3680-4250 |
7250-8100 |
9300-9680 |
||
|
Luminous Flux (lm) ±5% (Black finish) CRI80 |
1-CCT |
Non-DIM |
1280-1600 |
3420-4100 |
6930-7720 |
8530-9220 |
|
DALI |
1200-1500 |
3320-3850 |
6610-7340 |
8460-8770 |
||
|
2-CCT |
Non-DIM |
1260-1570 |
3375-4050 |
6880-7650 |
8460-9180 |
|
|
DALI |
1170-1500 |
3310-3820 |
6520-7290 |
8370-8710 |
||
|
Beam Angle (°) |
90° |
|||||
|
UGR |
<19 |
|||||
|
Dimming Option |
DALI |
|||||
|
Sensor |
Microwave sensor & Daylight sensor |
|||||
|
Emergency |
YES |
|||||
|
Product weight(Kg) |
N.W/PC |
2.61 |
5.96 |
7.17 |
10.83 |
|
|
G.W/PC |
3.07 |
6.79 |
- |
- |
||
|
Package weight(Kg) |
N.W/CTN |
15.66 |
11.92 |
- |
- |
|
|
G.W/CTN |
19.84 |
14.74 |
9.85 |
13.82 |
||
|
Qty/CTN (PCS) |
6 |
2 |
1 |
1 |
||
|
Carton Size(cm) |
64.5*46.5*47.5 |
68.5*23.5*68.5 |
85.5*14*89 |
111.5*14*112 |
||
|
20GP(pcs) |
1008 |
486 |
256 |
164 |
||
|
40HQ(pcs) |
2580 |
996 |
584 |
392 |
||
