AL228 is a ceiling light designed in Nordic style, with its shell and lampshade both made of high-quality PC materials, ensuring durability and showing texture. The light is equipped with high-lumen led chip, ensuring bright and efficient lighting. The lighting is uniform and soft, creating a warm and comfortable atmosphere in the space. Additionally, the AL228 ceiling light offers a variety of functions to meet various usage needs. Users can easily adjust the brightness and color temperature of the light to create personalized lighting effects. Installation is simple, with options for both back cable entry and side cable entry, suitable for different residential and commercial lighting scenes.
Applications: Suitable for semi-outdoor places such as corridors and hallways.
| Code | AL228-12-24W-A3 | AL228-16-30W-A3 | ||
|---|---|---|---|---|
| Dimension(mm) | Ø300*H70 | Ø400*H78 | ||
| Watt(W) | 24W Max. (18W/12W optional) | 30W Max. (24W/18W optional) | ||
| Rated Input Voltage | AC 220-240V | |||
| Input Voltage | AC198-264V | |||
| Light Source | SMD | |||
| SDCM | SDCM<6 | |||
| CCT(K) | 1-CCT: 3000K/4000K || 2-CCT: 3000K + 4000K | |||
| CCT Selection DIP Switch | YES | |||
| Luminous Flux (lm) ±5% CRI80 | 1-CCT | Non-DIM | 24W: 2700-3100 18W: 1960-2220 12W: 1300-1470 | 30W: 3480-4000 24W: 2950-3330 18W: 2090-2400 |
| DIM | 24W: 2650-3060 18W: 1700-2040 12W: 1250-1440 | 30W: 3210-3680 24W: 2720-3130 18W: 1960-2230 | ||
| 2-CCT | Non-DIM | 24W: 2700-3100 18W: 1960-2220 12W: 1300-1470 | 30W: 3480-4000 24W: 2950-3330 18W: 2090-2400 | |
| DIM | 24W: 2650-3060 18W: 1700-2040 12W: 1250-1440 | 30W: 3210-3680 24W: 2720-3130 18W: 1960-2230 | ||
| CRI | CRI 80 | |||
| Beam Angle(°) | 120° | |||
| LED Driver | Built-in, Flicker Free | |||
| Dimming Option | Triac / DALI | |||
| Sensor | Microwave sensor & Daylight sensor | |||
| Emergency Kits | YES | |||
| Electrical Class | Class II | |||
| Ingress Protection(IP Rating) | IP54 | |||
| Impact Resistance(IK Rating) | IK10 | |||
| Product Finishing | White RAL9016 | |||
| Optics Material | PMMA/PC | |||
| Housing Material | PC | |||
| Lifetime(hr) | 50,000h | |||
| Glow wire test(°C) | 750°C | |||
| Operating Temp.(°C) | -20°C~45°C | |||
| Storage Temp.(°C) | -20°C~60°C | |||
| Installation | Surface mount / Wall mount | |||
