The AL202 series adopts frameless and right-angled design, with sleek and elegant lines, providing a clean and comfortable appearance. To ensure maximum illuminated area, the product is designed with light-emitting surfaces on both the sides and front, enabling comprehensive illumination with uniform and soft light, delivering a warm and comfortable experience.
Application Areas: It is widely used in office, shopping mall, home, balcony, hotel etc.
| Code | AL202-12-18W-SB2-I04 | AL202-12-25W-SB2-I04 | AL202-16-25W-SB2-I04 | AL202-16-30W-SB2-I04 | ||
|---|---|---|---|---|---|---|
| Dimension(mm) | Ø300xH59 | Ø400xH59 | ||||
| Cutout(mm) | - | |||||
| Watt(W) | 18W | 25W | 25W | 30W | ||
| Rated Input Voltage | AC220-240V | |||||
| Input Voltage | AC198-264V | |||||
| LED Module Input | - | |||||
| Light Source | SMD | |||||
| SDCM | <6 | |||||
| CCT(K) | 1-CCT: 3000K/4000K/ || 2-CCT: 3000K + 4000K | |||||
| CCT Selection DIP Switch | Yes | |||||
| Luminous Flux (lm) ±5% CRI80 | 1-CCT | Non-DIM | 1900-2250 | 2440-3050 | 2550-3100 | 3150-3800 |
| DIM | - | |||||
| 2-CCT | Non-DIM | 1900-2250 | 2440-3050 | 2550-3100 | 3150-3800 | |
| DIM | - | |||||
| CRI | ≥80 | |||||
| Beam Angle (°) | 130° | |||||
| UGR | - | |||||
| LED Driver | Driver built-in | |||||
| Dimming Option | No | |||||
| Sensor | Microwave sensor+Daylight sensor | |||||
| Emergency Kits | No | |||||
| Electrical Class | Class II | |||||
| Ingress Protection(IP Rating) | IP54 | |||||
| Impact Resistance(IK Rating) | IK03 | |||||
| Product Finishing | White RAL9016 | |||||
| Optics Material | PC | |||||
| Housing Material | PC | |||||
| Lifetime (hr) | 50,000H | |||||
| Glow wire test (°C) | 750°C | |||||
| Operating Temp.(°C) | -20°C ~45°C | |||||
| Storage Temp.(°C) | -20°C ~60°C | |||||
| Installation | Surface mount / Wall mount | |||||
