This ceiling lamp features a delicate design with a simple and modern overall shape that perfectly blends with various interior styles. The light is soft, creating a warm and comfortable atmosphere, making it suitable for bedrooms, living rooms, studies, and other spaces. Its ultra-thin design takes up minimal height in the room, adding a sensor of simplicity to the interior. The material quality is excellent, with a delicate and smooth surface that showcases elegant taste. Whether in terms of lighting effect or visual appeal, it offers an ideal choice for home and commercial environments.
Applications: This product is suitable for general lighting in various settings such as offices, supermarkets, stores, schools, and hotels. It is also widely used in public areas like staircases, lobbies, reception areas, and corridors.
| Code | AL08-10-12W-A3C3 | AL08-14-24W-A3C3 | AL08-16-30W-A3C3 | ||
|---|---|---|---|---|---|
| Dimension(mm) | Ø250*47 | Ø350*45 | Ø400*52 | ||
| Cutout(mm) | - | ||||
| Watt(W) | 12W Max. | 24W Max. | 30W Max. | ||
| (10W/8W optional) | (18W/12W optional) | (24W/18W optional) | |||
| Rated Input Voltage | AC220-240V | ||||
| Input Voltage | AC198-264V | ||||
| LED Module Input | - | ||||
| Light Source | SMD | ||||
| SDCM | <6 | ||||
| CCT(K) | 3-CCT: 3000K + 4000K+5700K | ||||
| CCT Selection | By DIP Switch | ||||
| Non-DIM | 12W: 1230-1430 | 24W: 2930-3180 | 30W: 3930-4270 | ||
| Luminous Flux (lm) ±5% | 3-CCT | 10W: 1000-1160 | 18W: 2190-2350 | 24W: 3170-3410 | |
| CRI80 | 8W: 780-900 | 12W: 1450-1560 | 18W: 2400-2570 | ||
| DIM | 12W: 1270-1480 | 24W: 2750-2930 | 30W: 3670-3910 | ||
| 10W: 1190-1260 | 18W: 2010-2150 | 24W: 2960-3210 | |||
| 8W: 900-1030 | 12W: 1290-1370 | 18W: 2250-2390 | |||
| CRI | 80 | ||||
| Beam Angle(°) | 120° | ||||
| UGR | - | ||||
| LED Driver | Built-in, Flicker Free | ||||
| Dimming Option | Triac | ||||
| Sensor | Microware sensor | ||||
| Emergency Kits | NO | ||||
| Electrical Class | Class II | ||||
| Ingress Protection(IP Rating) | Ceiling surface mount IP54 | ||||
| Impact Resistance(IK Rating) | IK08 | ||||
| Product Finishing | White RAL9016 | ||||
| Optics Material | PC | ||||
| Housing Material | PC | ||||
| Lifetime(hr) | 50,000h | ||||
| Glow wire test(°C) | 750°C | ||||
| Operating Temp.(°C) | -20°C ~45°C | ||||
| Storage Temp.(°C) | -20°C ~60°C | ||||
| Installation | Surface mount | ||||
