600MM 12W Microwave Batten Light

FEATURES

  • Aluminum components generate a rust-free product for less maintenance
  • PC Diffuser
  • Up to 70% energy saving compared to standard CFL
  • Environment friendly, without Mercury or any other hazardous substances

CHARACTERISTIC

power factor 120 degree beam angleip54 waterproofeasy installation

APPLICATION AREAS

office lightingclassroom lightinginterior lighting ideasretail store lightingworkshop lightingled warehouse lighting

CERTIFICATIONS

RoHs certification

POLAR DIAGRAM COMPARISON

Microwave sensor led batten linear polar chart

DIMENSION

600mm cool white led linearled batten lights australia sizes chart

TECHNICAL SPECIFICATIONS

Power Voltage Power Factor Lumen (±5%) Beam angle CCT Lifespan CRI Dimmable Dimension
12W AC230V ≥0.9 1200 120° 3000K 40000h ≥80 No L620*W70.5*H83mm
12W AC230V ≥0.9 1260 120° 4000K 40000h ≥80 No L620*W70.5*H83mm
12W AC230V ≥0.9 1240 120° 5000K 40000h ≥80 No L620*W70.5*H83mm
12W AC230V ≥0.9 1220 120° 5700K 40000h ≥80 No L620*W70.5*H83mm
