25W COB LED Downlight

FEATURES

  • Up to 70% energy saving compared to standard CFL
  • Long lifetime of 40,000 hours
  • Dimmable when using triac dimmer
  • 24°/45°/60° wide beam angle
  • CCT: 2700K 3000K 4000K 5000K
  • No UV/IR light
  • Environment friendly, without Mercury or any other hazardous substances

CHARACTERISTIC

power factorled beam angle 24 degree45 degree beam angleled beam angle 60 degree ip54 waterproofeasy installation

APPLICATION AREAS

retail store lightingrestaurant lightingoffice lightingclassroom lightinginterior lighting ideas

CERTIFICATIONS

ce certificationRoHs certificationsaa certification

POLAR DIAGRAM COMPARISON

surface downlight polar curve

DIMENSION

sizes of surface mounted downlight ledDimensions 120mm cut out downlight

TECHNICAL SPECIFICATIONS

Power Voltage Power Factor Lumen (±5%) Beam angle CCT Lifespan CRI Dimmable Dimension
25W AC100-240V ≥0.9 2500 24°/45°/60° 2700K 40000h ≥80 No Ø120*110mm
25W AC100-240V ≥0.9 2700 24°/45°/60° 3000K 40000h ≥80 No Ø120*110mm
25W AC100-240V ≥0.9 2850 24°/45°/60° 4000K 40000h ≥80 No Ø120*110mm
25W AC100-240V ≥0.9 2850 24°/45°/60° 5000K 40000h ≥80 No Ø120*110mm
25W AC230V ≥0.9 2400 24°/45°/60° 2700K 40000h ≥80 Yes Ø120*110mm
25W AC230V ≥0.9 2600 24°/45°/60° 3000K 40000h ≥80 Yes Ø120*110mm
25W AC230V ≥0.9 2750 24°/45°/60° 4000K 40000h ≥80 Yes Ø120*110mm
25W AC230V ≥0.9 2750 24°/45°/60° 5000K 40000h ≥80 Yes Ø120*110mm
