10W Dimmable LED Downlight

FEATURES

  • Up to 70% energy saving compared to standard CFL
  • Long lifetime of 50,000 hours
  • Dimmable when using triac dimmer
  • 90° wide beam angle
  • 90-95mm cutout
  • CCT: 3000K 4000K 5700K
  • No UV/IR light
  • Environment friendly, without Mercury or any other hazardous substances

CHARACTERISTIC

power factorled beam angle 90 degreeip54 waterproofDimmable

APPLICATION AREAS

retail store lightingrestaurant lightingclassroom lightingsupermarket led lighting

CERTIFICATIONS

ce certificationRoHs certification

POLAR DIAGRAM COMPARISON

90 degree photometric diagram

DIMENSION

Commercial 90mm Downlight Dimensions

Down light Dimensions Diagram

TECHNICAL SPECIFICATIONS

Power Voltage Power Factor Lumen (±5%) Beam angle CCT Lifespan CRI Dimension DIM
10W AC200-240V ≥0.9 800 90° 3000K 50000h ≥80 190*115*62mm cutout 90-95mm Yes
10W AC200-240V ≥0.9 940 90° 4000K 50000h ≥80 190*115*62mm cutout 90-95mm Yes
10W AC200-240V ≥0.9 870 90° 5700K 50000h ≥80 190*115*62mm cutout 90-95mm Yes
